Isomorphic React with Rails

12 Sep, 2015 · #dev #js #react

I’d like to share intermediate results of my work with Universal (aka “Isomorphic”) JavaScript apps, based on React library from Facebook and Ruby on Rails as a backend.

Actually, it’s not that much about Rails, but about JSON API. So if you don’t use/like Rails, just take it as an abstract API and keep reading.

If you haven’t heard about isomorphic javascript concept, here is the link that explains what it’s all about.

Planning the application

I’ve been trying to implement JS server side rendering within Rails app using react-rails gem, but it’s not the way to go. Tools play best in environments, for which they were designed. So I cut the whole front-end stuff out of Rails and moved it to Node.js.

Here is the first draft:

First draft

Rails, which became simply JSON API, is responsible for data and React handles UI part using the same javascript codebase on the server and on the client. Worth to note, we can use Rails as API for mobile app and other services interested in our data.

Let’s go deeper. When user hits http://my-app.com, request goes to a Node.js server with Express on top. We need data to render initial html and send a response. So we fetch it from Rails API via http request. When data are arrived, React renders a view and Express sends html to the client with JS app, which takes control over the flow. When a user hits some link on the site, app makes an ajax call to fetch new data and updates views on the client.

Front-end app lives on the main domain: http://my-app.com. But for API we have options:

my-app.com:3000
We can have it on the same domain, but on a different port. Then we are forced to keep 2 apps on the same server.
api.my-app.com
I prefer another option—put it on a subdomain (or another domain), so we can scale app in the future without changing a codebase.

Next we need to decide how data will be fetched from API.

###

Option 1. Ajax CORS requests

CORS

Because of the same-origin policy we can’t make ajax requests from one location to another (even if a target resource on the same domain but different port). To enable such kind of requests we must apply Cross-Origin Resource Sharing (CORS) mechanism.

If you’ll choose to go this way, you need to set special http headers on a Rails side. This way browser is verifying that caller have the rights to send ajax requests to this server.

Keep in mind that by enabling CORS (especially public access) you dig potential CSRF security hole. Read this carefully to mitigate CSRF attacks.

###

Option 2. Proxy ajax calls through front-end server

Proxy

Instead of enabling CORS, we can proxy requests through nginx front-end server. Every call goes to the same domain: my-app.com. Nginx splits it in two directions:

my-app.com/*
Almost all of requests are passed to Node.js app.
my-app.com/api/*
Except calls to /api, which are proxied to Rails API.

This approach is more secure and the whole system looks solid from outside. So we will go this way, but it requires some additional setup on local machine.

Local setup

Install nginx:

shell
brew install nginx

Edit nginx.conf:

shell
sudo $EDITOR /usr/local/etc/nginx/nginx.conf

Extend http block in the config with upstreams:

nginx
http {
  upstream app_proxy {
    server lvh.me:3500;
  }

  upstream api_proxy {
    server api.lvh.me:3000;
  }

  server {
    listen 80;
    server_name lvh.me;

    location / {
      proxy_set_header Host $http_host;
      proxy_set_header X-forwarded-for $proxy_add_x_forwarded_for;
      proxy_set_header X-NginX-Proxy true;
      proxy_pass http://app_proxy;
      proxy_redirect off;
    }

    location /api {
      proxy_set_header Host api.lvh.me;
      proxy_set_header X-forwarded-for $proxy_add_x_forwarded_for;
      proxy_set_header X-NginX-Proxy true;
      proxy_pass http://api_proxy/;
      proxy_redirect off;
    }
  }

  server {
    listen 80;
    server_name api.lvh.me;

    location / {
      proxy_set_header Host $http_host;
      proxy_set_header X-forwarded-for $proxy_add_x_forwarded_for;
      proxy_set_header X-NginX-Proxy true;
      proxy_pass http://api_proxy;
      proxy_redirect off;
    }
  }
}

Finally, run nginx:

shell
sudo nginx

Now you can visit http://lvh.me in your browser. There will be nginx error message. It’s ok, because Node.js app is not yet running.

Stop nginx for now:

shell
sudo nginx -s stop

###

Hosts

Also, you may want to add lvh.me to hosts file to avoid unnecessary roundtrips:

shell
sudo $EDITOR /private/etc/hosts

And add:

fe80::1%lo0   lvh.me
fe80::1%lo0   api.lvh.me

127.0.0.1     lvh.me
127.0.0.1     api.lvh.me

Follow up

You can find other posts of this series on my medium but they are pretty much out of date at this point.
